簡訊告警網路環控系統 WEB600


特色: 經濟、易用、方便,新一代高智能網上監控系統內置網路伺服器,無須安裝軟體亦能監察及操控系統。6個通用輸入點,可連接乾接點、溫度感應器及4-20mA輸入。 自動存取數據,發出電郵警報,可支援接Modbus、SNMP協議。

代碼 WEB600




Alarm notification methods

  • E-Mail, Text Messages, SNMP Traps

  • 8 Alarm escalation levels

  • Comprehensive scheduling per input,
    profile, and alarm destination

Destinations

  • 8 Programmable User Profiles

  • 4 programmable alarm destinations
    per profile

Communication types

  • E-Mail – SMTP

  • Text Messages

  • Web page – Supported formats

HTTP, PDA, WAP, and XML

  • SNMP– MIB with Traps,GET,
    GETNEXT, and SET

  • MODBUS®/TCP Slave Conformance
    Class 0 and 1

Communication Ports

  •  Ethernet 10/100Base–TWeight

Local indicators

  • Alarm Status LED

  •  Power Status LED

  • Ethernet link and Activity LEDs









Inputs

  • 6 Universal Inputs

  • Normally Closed /Normally Open Dry Contact

  • 2.8K / 10K Thermistor

  • 4-20mA Current Loop

  • 12 Bit Resolution Data logging

  • 32,000 Samples (all samples include data date and time)

  • 1 second to 1 month sampling rate

  • User programmable channel selection

  • Zones 1 – 6

  • Battery

  • Input PowerEnvironment

Power requirements

  • External transformer 120VAC 60Hz

  • Optional Battery Backup

Module (FGD-W610)

  • Provides 3 hours of backup

Operating conditions

  • 0-90% RH, non–condensing

  • 0-50°C (32–122°F)

Physical properties

  • 5.5” x 3.25” x 1.25”

  • 0.5lbs

Standards

  • FCC Part 15–B Compliant
